Product Description:
Features:
1. Precision Casting.
2. Efficient Production.
3. Automated Processes.
4. Rapid Mold Change Capability.
Technical Parameters:
| Properties | Parameters |
| Equipment Size:L*W*H | 5200*5000*3600mm |
| Total Weight | 13T |
| Total power | 125KW |
| Voltage | 380V |
| Max. Die Dimensions | 600*400*240mm |
| Max. Die Thickness | 2*120mm |
| Max. Die Opening stroke | 370mm |
| Max.Die Weight | 200Kg |
| Max. force of die closing | 2400KG |
| Max. force of ejector | 500KW |
| Max. die ejector stroke | 48mm |
| Furnace Melting rate | 350KG/H |
| Furnace Capacity | 1800KG |
| Furnace Inductors | 3*35KW |
| Hydraulic Motor Power | 8.7KW |
| Hydraulic Rated Pressure | 8Mpa |
| Hydraulic fluid temperature | ≤52℃ |
| Cooling system Water PH value | 7~8.5 |
| Cooling system Pressure | 3-5bar |
| Cooling system Temp. | 20±2℃ |
| Cooling system Flow | ≥400L/Min ≤600L/Min |
| Air pressure Compressed air pressure | 0.5-0.6Mpa |
| Air pressure Compressed air consumption | 15m³/H |
Applications:
1. Manufacturing Bathroom Accessories: Brass low-pressure casting machines are commonly used to
manufacture bathroom accessories such as faucets, showerheads,
faucet handles, and components for other sanitary equipment. The
high corrosion resistance and decorative properties of brass make
it an ideal material for bathroom products.
2. Water Meter Manufacturing: Brass low-pressure casting machines are used to produce the
casings and internal components of water meters. Brass's excellent
thermal conductivity and electrical conductivity make it an ideal
material for water meters, aiding in accurate water measurement and
recording.
3. Valve Manufacturing: Valves play a crucial role in industrial processes, and brass
low-pressure casting machines are employed to manufacture
high-quality valve components, ensuring their reliability and
durability.
4. Automotive Components: In the automotive manufacturing industry, brass low-pressure
casting machines can be used to produce various components such as
engine parts, brake components, and transmission system parts.
Instruments and Gauges: Some high-precision instruments and gauges
require brass parts to ensure their accuracy and stability
Support and Services:
We provide technical support and services for Low Pressure Die
Casting Machine. Our technical support and services includes:
- 24/7 customer service
- Installation and commissioning
- Troubleshooting and repair
- Maintenance and upgrades
- Spare parts supply
- Technical training
Our technical support and services team is committed to providing
you with the most comprehensive and reliable service available.
Packing and Shipping:
Packaging and Shipping for Low Pressure Die Casting Machine:
The Low Pressure Die Casting Machine will be securely packaged in
wooden crates equipped with foam cushioning and additional
wrapping. The crates will be labeled with the product information
and shipping details. All packages will be insured and shipped with
a reliable carrier.
